Function |
Intercom: The visitor presses calling button on the door
unit,and the end users can answer it from smart phone
with IOS/Android APP and have video intercom. |
|
Monitoring: Smart phone can monitor the outdoor unit |
|
Connect extra exit button |
|
Unlock: Open the door lock with smart phone APP |
|
Tamper alarm and receive the alarm message from smart
phone |
|
Night vision compensation with LED |
|
Picture memory in the smart phone |
|
Record backup: Check calling, alarm and other records |
|
Support maximum 5 smart phones from the calling of
outdoor unit |
|
Camera |
Resolution: VGA（640*480） |
|
Angle: 120~135 degree |
|
Codec |
Half-duplex intercom |
|
Audio Codec: PCMU |
|
Video Codec: H.264 |
|
Network |
WIFI connection，802.11b/g/n protocol |
|
Support the calling under LAN/WLAN status |
|
Saving data stream, upstream rate 9-13KB/S, downstream
rate 30-50KB/S |
|
Support SIP protocol and can communicate with SIP phone |
|
Power supply |
DC 12V |
|
Size & Installation |
Dimension: 86x160x55 |
|
Color：Silver/Black |
|
Material ：ABS palstics |
|
IP ratings: IP55 |
|
Installation: Surface mounted |
